Posted on 05/03/14 6:11:59 PM
Deborah Morley
Makeover Magician
Posts: 1319

Reply


Aligning 3D objects
I have been trying to make a 3D object which I then add more layers so I can apply different textures. Using the pen tool I trace around the bit I want to put a different texture, do the horizontal wraparound, then make the extrusion wider to fit the existing shape. I merge the layers, but it never seems to come out level with the original shape. I then spend ages trying to get them to align. As far as I know the original shape is level and on the ground plane. Is there any way that you can snap to a previous 3D shape?



Posted on 05/03/14 8:19:00 PM
Frank
Eager Beaver
Posts: 935

Reply


Re: Aligning 3D objects
Hi Deborah -- as far as I know there is no way to snap two objects together ( a feature I'd like to see and mentioned a couple of times to Steve) - the way I've been doing it is jumping back and forth between the various views and manually moving and sometimes using the co-ordinates and arrow keys to tap into place. I used to use Bryce 7 at one time and that had the option to snap together or to snap to object below as well as to join at various angles ( made things much simpler) Perhaps we'll see that down the road.


Posted on 06/03/14 07:36:33 AM
Steve Caplin
Administrator
Posts: 6334

Reply


Re: Aligning 3D objects
Merging layers can often produce misalignment, but there's a simple workaround.

Here's how your layers might look - completely unaligned:



Open the Properties panel, and you can see that the coordinates for each object are all over the place:



Click Reset Properties and then [/i]Move to Ground[/i], and the selected object will be zeroed:



Then repeat for the other object:



Now, when you change the angle of view, you'll be able to drag vertically to stack the objects so that they're precisely aligned:



What I don't really get, though, is why you're using the Pen tool to make selections. Can you explain this further?

Posted on 06/03/14 4:02:30 PM
Deborah Morley
Makeover Magician
Posts: 1319

Reply


Re: Aligning 3D objects
Thanks Frank, that was pretty much what I was doing.
Steve, I was using the pen tool to trace around the areas I wanted to add another texture to then extruding itů.Might have helped if I had read the piece 'filling a wine glass'. This time I duplicated the layer then edited the source to select the area I wanted the new texture. That worked, apologies for not reading all the book!!



Posted on 07/03/14 07:19:06 AM
Steve Caplin
Administrator
Posts: 6334

Reply


Re: Aligning 3D objects
You can add multiple textures to a single object, as well. Have a look at the section on painting on texture, and you'll see how you can work out how the texture map aligns with the layer.

Posted on 07/03/14 09:34:33 AM
Deborah Morley
Makeover Magician
Posts: 1319

Reply


Re: Aligning 3D objects
I must admit I get a bit confused with materials and textures. But am I right in that with the 3D shape I did, I needed 3 layers to get differing amounts of 'shine' for the wood, stone and marble?
If I was just using one 'material' as in stone then I could do the painting on texture?
I will try it.

Posted on 07/03/14 10:38:10 AM
Steve Caplin
Administrator
Posts: 6334

Reply


Re: Aligning 3D objects
You can create masks for each attribute, so you can control the amount of shine etc on each part of the model. A bit fiddly, but it does mean you could construct this whole object as a single unit.
